Bridge Construction

Grade 6 Gifted & Talented

  •



    Balsa Wood Bridge Challenge



    The Challenge: Design and build a Balsa wood bridge that holds as much weight as possible.



    The Reward: The bridge that holds the most weight will be considered the 2016-2017 JMUES Bridge Engineer Champion. There will be one champion per grade level. Champions will be invited to a lunch celebration with Mrs. Fowler and up to three friends from their PLT that includes pizza and a dessert of their choice.



    Materials:

    • 10 pieces of 1/8” x 1/8” Balsa wood. Each piece measures 24” in length.
    • Cutting tools
    • Elmer’s Glue
    • Pins and clamps



    Bridge Specifications:



    • Span: exactly 30 cm
    • Length: between 35 to 40 cm
    • Width: exactly 8 cm
    • Minimum height: 3 cm
    • Maximum Mass: 18 Grams



    The Fine Print: Lamination is not allowed. The superstructure must be above the roadway. Substructures are allowed and can extend no more than 8 centimeters below the roadbed. The substructure must be a minimum of 3 centimeters shorter than the span of the bridge. There must be a platform or flat space of some kind large enough for the testing device to rest stably on the bridge.



    Presentations: Engineers are required to document their progress using a combination of note-taking and photographs. Each engineer will be responsible for creating a Photostory after the bridges have been tested. Each presentation must include the following:

    • Explain your style: which truss/bridge type did you choose? What appealed to you?
    • Efficiency Score & calculations
    • Bridge Dimensions
    • Improvement Options
    • Photos with descriptions that show the progress of the project
